FBG Hydrostatic Level Sensor

The FBG Hydrostatic Level Sensor HS-01 is a high-precision pressure monitoring system designed to measure the relative settlement of multiple points. In application, a series of FBG sensors are connected by connecting pipes. The pressure of each measuring point is measured by the sensor. Each sensor is composed of a pressure measuring fiber grating and a temperature measuring fiber grating. The sensor is composed of a sensing film to sense the change of water pressure and transmit it to the pressure grating. The sensor performs temperature compensation to correct the drift of sensor data caused by changes in external temperature.


Features of FBG Hydrostatic Level Sensor HS-01

  • Anti-vibration

  • Compact size

  • Installation level of the base is not required

  • Slow liquid volatilization

  • Safe during installation

  • Easy to maintain

Application of FBG Hydrostatic Level Sensor HS-01

  • Bridges

  • Hydropower plants

  • Dams

  • High-rise buildings

  • Nuclear power plants

  • Water conservancy project rock masses

Specification of FBG Hydrostatic Level Sensor HS-01


ParameterUnitValue
Center Wavelengthnm1460 ~ 1610
Rangemm200
Resolutionmm0.1
Accuracymm1
Temperature Compensation--Built-in
Material--Stainless steel
Installation--Expansion bolt
DimensionmmΦ76 x 128
Pigtail LengthmΦ3mm armored cable, 1m at single end, or customize
Optical Connector--FC/APC, or customize
Operating Temperature°C-20 ~ +80
